4 1/2 CSG Thread Plug Gage

4 1/2 CSG Thread Plug Gage PER API 5B made In China , delivery time:in stock

Introduction to API 5B Thread Gauges and Sowant Precision Gage’s Capabilities

API 5B is a globally recognized standard for thread gauges used in oilfield tubular goods, ensuring precision and compatibility in casing, tubing, and line pipe connections. This article focuses on key thread gauge types under API 5B—LP (Line Pipe), CSG (Casing Short Round Thread), BCSG (Buttress Casing Thread), TBG (Tubing Round Thread), and UPTBG (Upset Tubing Thread)—with a detailed examination of the 4 1/2" CSG Plug Gauge and the comprehensive range of CSG thread gauges. Additionally, we highlight the expertise of Sowant Precision Gage Co., Ltd. in supplying high-quality measurement tools, including Mitutoyo products and specialized thread gauges.

API 5B Thread Gauges: Standards and Applications

1. CSG (Casing Short Round Thread)

   • 4 1/2" CSG Plug Gauge:

     • Specifications:

       • Outer Diameter: 114.3 mm

       • Pitch: 3.175 mm (8 threads per 25.4 mm)

       • Taper: 1:16

       • Thread Angle: 60° .

     • This gauge is critical for inspecting short-round casing threads, ensuring compliance with API 5B standards for sealing and mechanical strength.

   • Full Range of CSG Thread Gauges:
     CSG gauges cover sizes from 4 1/2" to 20", with standardized parameters across all dimensions (see table below) :

     Size (inches)	Outer Diameter (mm)	Pitch (mm)	Taper	Thread Angle
     4 1/2	114.3	3.175	1:16	60°
     5	127	3.175	1:16	60°
     5 1/2	139.7	3.175	1:16	60°
     6 5/8	168.28	3.175	1:16	60°
     ... (up to 20")	...	...	...	...

2. Other API 5B Thread Gauges :

   • LP (Line Pipe): Covers 1/8" to 12", used for pipeline connections.

   • BCSG (Buttress Casing): Designed for sizes 4 1/2" to 6", offering enhanced load-bearing capacity.

   • TBG/UPTBG (Tubing Threads): Applied to tubing connections (1.050" to 4 1/2"), with UPTBG featuring upset ends for higher pressure resistance.

Sowant Precision Gage: Your Trusted Partner in Measurement Solutions

Based in Suzhou, China, Sowant Precision Gage Co., Ltd. (established in 2009) specializes in supplying advanced measurement instruments and thread gauges. Their offerings include:

1. Comprehensive Range of Mitutoyo Products:

   • Thread Gauges: Such as the Mitutoyo 188-130 Metric Thread Pitch Gauge (0.35–6 mm, 22 blades) .

   • Thread Micrometers: Including models like the 125-105 for measuring unified and metric threads .

2. Global Brand Partnerships:

   • Authorized distributor for Tesa, Trimos, Sylvac, Mahr, and others, ensuring access to premium European and American measurement tools .

3. Specialized Thread Gauges:

   • Acme/Stub Acme Thread Gauges: For trapezoidal thread inspection.

   • Tr (Trapezoidal) Thread Gauges: Used in power transmission systems.

   • Customizable OEM services for API and non-API gauges .

Why Choose Sowant Precision Gage?

• Quality Assurance: All products meet ISO and API standards, with calibration certificates provided.

• Rapid Delivery: Standard lead time of 3–5 days for API 5B gauges .

• Technical Support: Dedicated customer service for industrial and laboratory applications.

For inquiries or customized solutions, contact Sowant Precision Gage at +86-13862064056 or visit their headquarters in Wusongjiang Business District, Suzhou .

Explore the full catalog of API 5B thread gauges and Mitutoyo instruments at Sowant Precision Gage—your gateway to precision measurement.
