1.25-5 ACME-2G LH MOD

1.25-5 ACME-2G LH MOD thread ring gages per the ASME B1.5
ꄴPrevious： 4 1/4-4 Stub Acme-2G
ꄲNext： 4"-4HBPV LH Thread Ring

Precision-Engineered ACME-2G LH MOD Thread Ring Gages by Sowant Precision Gage

Sowant Precision Gage is a renowned manufacturer of high-precision inspection tools, dedicated to ensuring the utmost accuracy and quality in industrial measurement. We are proud to introduce our specialized line of modified (MOD) ACME-2G Left-Hand thread ring gages, engineered for applications requiring custom thread profiles beyond standard specifications.

This particular product, the 1.25-5 ACME-2G LH MOD thread ring gage, is designed for inspecting left-hand ACME threads that have been modified from the standard ASME B1.5 dimensions. The "MOD" designation indicates that this gage is not built to the standard thread form. Instead, it is manufactured based on specific modification data provided by the customer to match their unique product thread precisely. This ensures a perfect and accurate inspection process for your custom threaded components.

Key Product Features & Specifications:

  • Gage Type: Modified (MOD) Thread Ring Gage

  • Thread Standard: Based on ASME B1.5 for core design, with custom modifications.

  • Thread Direction: Left-Hand (LH)

  • Material: Bearing Steel Cr 15. This high-carbon, high-chromium steel offers exceptional hardness, superior wear resistance, and outstanding durability, significantly extending the gage's operational lifespan in high-use environments.

  • Lead Time: 4 weeks from the receipt of order and confirmed modification data.

  • Crucial Requirement: To manufacture this custom gage, customers must provide all relevant modification data for their product thread (e.g., pitch diameter adjustment, thread form alteration). Production will commence only after all data has been received and confirmed.

30 Example Specifications of ACME Thread Ring Gages (2" Nominal Diameter Range)

Below is a list of 30 potential specifications for ACME thread ring gages in the approximate 2-inch nominal diameter range, showcasing a variety of thread sizes and classes. The MOD version would be custom-built based on any of these standard sizes.

  1. 5-4 ACME-2G LH thread ring gage

  2. 5-4 ACME-3G LH thread ring gage

  3. 6-4 ACME-2G LH thread ring gage

  4. 6-4 ACME-3G LH thread ring gage

  5. 7-4 ACME-2G LH thread ring gage

  6. 7-4 ACME-3G LH thread ring gage

  7. 8-4 ACME-2G LH thread ring gage

  8. 8-4 ACME-3G LH thread ring gage

  9. 9-4 ACME-2G LH thread ring gage

  10. 9-4 ACME-3G LH thread ring gage

  11. 10-5 ACME-2G LH thread ring gage

  12. 10-5 ACME-3G LH thread ring gage

  13. 11.75-5 ACME-2G LH thread ring gage

  14. 11.75-5 ACME-3G LH thread ring gage

  15. 14-5 ACME-2G LH thread ring gage

  16. 14-5 ACME-3G LH thread ring gage

  17. 2.00-5 ACME-2G LH thread ring gage

  18. 2.00-5 ACME-3G LH thread ring gage

  19. 13-5 ACME-2G LH thread ring gage

  20. 13-5 ACME-3G LH thread ring gage

  21. 15-5 ACME-2G LH thread ring gage

  22. 15-5 ACME-3G LH thread ring gage

  23. 16-5 ACME-2G LH thread ring gage

  24. 16-5 ACME-3G LH thread ring gage

  25. 18-5 ACME-2G LH thread ring gage

  26. 18-5 ACME-3G LH thread ring gage

  27. 2.00-6 ACME-2G LH thread ring gage

  28. 2.00-6 ACME-3G LH thread ring gage

  29. 2.125-6 ACME-2G LH thread ring gage

  30. 2.125-6 ACME-3G LH thread ring gage

Ordering Information:

When ordering a modified (MOD) gage, please specify the base standard size (e.g., 2.00-5 ACME-2G LH) and be prepared to submit all necessary modification data. Our engineering team will work closely with you to ensure the final gage meets your exact inspection requirements.

For pricing, detailed technical consultation, or to place an order, please contact our sales department.

Sowant Precision Gage — Your Partner in Precision Measurement.
